We have modern technology and machinery, with expertise in producing many types of wires according to customer needs with world-class standards.
FEATURES
General purpose cable for automobiles , they are used in low voltage circuits such as starting charging , lighting , signal and instrument panel circuits.
Standard to JIS C 3406 , JASO : D611
Download
FEATURES
Constructed thinner than AV wires while providing equivalent performance. Standard to JASO D611
Download
FEATURES
AVSS wires are still thinner than type AVS wires while ensuring equivalent performance. Light weight and small diameter type type AVSS wires are best for
wiring harness.
Conformity to JASO D611
Download
FEATURES
The insulation of AVSSH wires has been changed to’non-cross-linked’ , and this change has realizedlow-cost wires because the irradiation process was eliminated.
Standard to JASO D611
Download
FEATURES
Insulation : PVC 85°CConductor : JIS C3102
Temperature : -40oC~85°CFlame retardant : ISO 6722 Resistance to flame propagation angle of 45
Standard : JASO D611
Download
FEATURES
Conductor : Soft-Annealed copper ,
Conductor according to ISO 6722-1
Insulation : Lead-free polyvinyl chloride ,
according to ISO 6722-1 , Class B
Standard : ISO 6722-1 , Ford ES-AU5T-1A348-AA , GM GMW15626
Download
FEATURES
HEB wires are thick-walled (heavy-duty) wires with increased mechanical strength.grounding (minus side)Conformity to JASO D611
Download
